| Model: JCP-1.3/1.6M | Automatic pipe cutting machine |
| Abstract | |
| ＊ Native range | Automatic cutting of 3mm paper tube |
| ◎ Cutting shaft width | 1400-1700mm |
| ◎ Cutting width | 36mm – 500mm |
| ◎ Cut the inner diameter of paper core | 3'' |
| ◎ Maximum cutting thickness | max3mm |
| ◎ Service voltage | 380V 50HZ 3PHASE |
| ◎Use an air pressure source | 5KG (Customer's own) |
| ＊ Host equipment | |
| ◎ Spindle motor | AC 3 HP Dongyuan motor inverter control |
| ◎ Cutter control system | Hydraulically controlled feed |
| ◎ Sliding part | High precision linear steel ball rail |
| High precision ball screw | |
| ◎ Control system | Taiwan FATEK PLC, automatic fault detection system |
| ◎ Touch screen | Touch LCD display (color 10") |
| ◎ Safety shield | All-machine safety shield |
| ＊ Loading equipment | |
| ◎ Rotary tube blanking mechanism | Rotary tube feeding mechanism |
| ◎ Paper tube mechanism | Reducer control automatic paper tube |
| ＊ Discharge equipment | |
| ◎ Servo control discharge mechanism | Automatic discharge controlled by servo motor (can realize the separation of head and tail) |
| ◎ Pneumatic control push arm | Pneumatic push arm |
| ＊Tool installation | |
| ◎Fixed upper tool set | Adopt fixed upper tool group |
| ◎ Cutting width | Standard 48mm width upper tool shaft |
