Product Description
Features:
All kinds of paper, film and other materials are cut and rewound.
Specifications:
*Z Large winding diameter: 650mm
* Coiling core diameter: 3-6"
* Manufacturing width: 1M-1.8M
*Z Large feeding diameter: 1200mm
*Z small slitting width: 50mm
* Mechanical Z High speed: 300M/Min
peculiarity
1. Coiling power part: two coiling motors cooperate with the main motor to do three-motor continuous control, the main motor separates the feeding motor and the winding motor to control the tension, the tension of the finished product is stable, and the appearance is beautiful.
2. Winding machine part: the winding shaft adopts slip system, which can automatically adjust the winding tension when winding, and the effect is better for materials with uneven thickness.
3. Motor control part: The operation interface adopts the LCD touch screen, which can directly set various winding conditions and operating conditions on the screen. The control part uses a programmable controller for mechanical action control, and has a self-testing system. When the machine fails, it can diagnose the fault cause by itself.
4. Flyover type walking: The material is used in the bridge type walking before the knife, which is convenient to operate and can prevent the static electricity on the material from absorbing the dust on the ground.
5. Auxiliary pulling device: When the material is rolled out, it can be assisted by the motor to pull the material, saving the pulling time and reducing the material loss.
6. Basic discharge form: separate discharge stand, discharge diameter is large, and the space possibility of installing other devices is greater.
Optional accessories
1. Auxiliary feeding of raw materials: The use of hydraulic power, suitable for the workshop without driving, can save manpower and shorten the loading and unloading time.
2. Discharge part muffler cover: reduce the noise generated when the material is rolled out and improve the quality and safety of the working environment (suitable for tape).
3. Ear material handling device: Optional independent or connected wire winding machine to pick up waste, in addition to strong windmill can be used for non-viscous materials.
4. Automatic line setting device: suitable for slitting after printing, which can accurately align with the printing reference line and slitting.
